Vial Liquid Filling Stoppering Machine

Product Introduction：
The Vial Liquid Filling and Stoppering Machine is designed for precision liquid filling and automatic stoppering of sterilized pharmaceutical vials.
It integrates vial feeding, liquid filling, stopper feeding and stoppering in one compact system. Multiple filling heads and pump options can be configured according to the liquid properties, filling volume and required output.
Key Benefits：

Precision liquid filling
Multiple filling-head configurations
Peristaltic or plunger pump options
Anti-drip filling design
Automatic stopper feeding and insertion
Adjustable filling volume
No bottle, no filling
PLC touchscreen control
Optional laminar airflow protection
Connects with freeze dryers and capping machines


Availability:



Inquire Add to Basket

Product Description

Technical Parameters

Application

Product Features

Flexible Filling Systems

Available filling systems may include:

Peristaltic pump
Ceramic plunger pump
Metal plunger pump
Other customized dosing systems

Accurate Volume Adjustment

Filling volume, speed and other operating parameters can be adjusted through the touchscreen.

Anti-Drip Filling

The filling-needle structure and controlled filling motion help reduce dripping, splashing and contamination around the vial opening.

Automatic Stoppering

The machine automatically feeds and inserts rubber stoppers after filling. Partial stoppering can be configured for lyophilization applications.

Technical Parameters

Product Model	MYXY-4	MYXY-6	MYXY-8	MYXY-10	MYXY-12	MYXY-20
Specification(ml)	2-30ml
Output(pcs/min)	50-100	80-150	100-200	150-300	200-400	250-500
Filling Heads	4	6	8	10	12	20
Powder Supply	380V 50Hz
Stoppering Qualified Rate	>=99%
Laminar Cleanliness	100grade
Vacuum Pumping Speed	10m3/h	30m3/h	50m3/h	60m3/h	60m3/h	100m3/h

Application

The machine is mainly suitable for filling, capping and cap screwing (capping) of various low-dose liquids like penicillin. It is widely applied in such fields as pharmaceutical, food and chemical industries and scientific research institutions. It can be used separately or together with the bottle washing machine, tunnel dryer sterilizer to form a production line. It meets the GMP requirements and accepts electrical configuration upgrade requirements of customers.
